Double Offset Rubber Seated Wafer Type Butterfly Valve
Description
Size Range
3“ To 60” (80MM To 1500MM)
Tempreature Range
Upto 220°C
Pressurre Class
PN 50
Shutoff Rating
Tight Shut Off
Body Style
Wafer Type
Flange Drilling
150#, 300#, AWWA, Series-A, Series-B, EN 1092-1, EN 1092-2
Body Materials
WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY - 20
Stem Materials
SS 304 / 316 / 410 / 17-4 PH / 316L / NITRONIC - 50 / DUPLEX 4A / 5A / 6A / 7A
Seat Materials
EPDM, EPDM - H, VITON
Disc Materials
WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY - 20
Design Standard
BSEN 593, ISI 3095, API 609, AWWA C 504
Testing Standard
API 598, BSEN - 12266-1, AWWA C 504
Face To Face
API - 609, BSEN 558, AWWA C 504 / 516
End Connection
150#, 300#
Features & Benefits
1 – Double Offset Design: Reduces friction and wear, enhancing performance and extending valve life.
2 – Rubber Seat: Provides a reliable, tight seal to minimize leakage.
3 – Wafer Type Construction: Facilitates easy installation between flanges and saves space.
4 – Versatile Application: Suitable for water, wastewater, and other fluid handling systems.
5 – Durability: Designed for long-lasting performance and cost-effectiveness.
6 – Compact and Lightweight: Ideal for various industrial and commercial settings.
